Taurus – TB6

« Back to series


Novastar logo2
Download specification PDF


The Novastar Taurus series TB6 is a new all-in one solution which combines sending card and media player into one device.

The internal media player can playback content from USB drive or internal memory, it’s also equipped with HDMI input and loop. Equipped with 1.5Ghz eight-core processor, the TB6 offers smooth playback of high definition content.
The integrated access point enable you to easily upload content by mobile phone or tablet, you can also use a wired LAN network to control all settings of the TB6, including screen configuration. The optional available 4G module allows you to access the TB6 anywhere even when there is no LAN network available.

The internal sending card has two integrated sensor inputs, therefore light and temperature sensors can be connected directly to the device. The TB6 also has two main output ports which are capable of controlling up to 1.300.000 pixels and two fixed back-up ports, making it suitable for small to medium size led displays projects.
  • All-in-one solution: media player and sending card with scaling function
  • Up to 2.300.000 pixel capacity
  • HDMI Input and loop
  • 4 x Ethernet output port
  • Built-in Wi-Fi Access point, easy content upload by smart phone or tablet
  • On-board Temperature / Light sensor input port
  • Audio output

TB6 Features

Control Method WiFi / Gigabit network Interface
Local content upload 2x USB 2.0 port for playback or media import from USB drives
Remote content upload Remote content upload by smart phone or tablet
Output Interface HDMI 1.3 (Loop) 4x Ethernet output port (2xMain / 2x fixed Backup)
Pixel capability Up to 1.300.000 pixels, maximum width 4096 pixels and maximum height 1920 pixels
Input interface HDMI 1.3
Supply voltage AC-100-240V-50/60HZ
Internal storage 8GB on-board, 4GB available for users
Processor 1.5 GHz eight-core processor
